ARC 400 AMPS IJ2 Moduler IGBT
.jpg)
ARC 400 AMPS IJ2 Moduler IGBT
Instantly view on mobile scan this picture
ARC 400 AMPS IJ2 Moduler IGBT
Description:
Reliable,Rugged,Heavy Duty Industrial Professional Choice.
- Robust and easy to use.
- Digital instrument for the welding current.
- On the front panel knob to adjust the parameter Hot Start.
- On the front panel knob to adjust the parameter Arc Force.
- Equipped with VRD system for your safety.
- Auto-Protection against over-voltage, over-current and over-heated.
- Equipped with four wheels to facilitate handling.
- Socket for connecting the remote control.
- This equipment is protected by a solid metal casing.
| Parameters | Specification |
|---|---|
| Rated Input Voltage(V) | AC380V±15% 3P |
| Efficiency(%) | 85 |
| Rated Input Current(A) | 27.6 |
| Power Factor | 0.93 |
| Input Frequency(HZ) | 50/60 |
| Protection Grade | IP21 |
| Rated Input Power(KVA) | 10.2 |
| Weight(kg) | 33 |
| Current Range(A) | 40-400 |
| Electrode Diameter(mm) | 1.6-5.0 |
| Open Circuit Voltage(V) | 68 |
| Dimension(mm) | 550*280*545 |
| Duty cycle at maximum current | 60%@40 |
Standard Accessories:
- ARC Holder With Cable
- Earth Clamp With Cable
Electrode Capacity
| Electrodes | Tickness (mm) | Additional Information |
| Stainless Steel, Mild Steel | 2.5 mm - 4.0 mm | 7018 - Gouging use, Low Hydrogen Hard Facing Electrode |
